| MR30 |
|
|
|
AG60 |
MR6
|
MS12 |
 |
Type |
Output speed n2 rpm |
Transmission- ratio
DC 60% |
Transmission- ratio |
Motor- speed n2 [min-1] |
Motoroutput [kW]
DC 60%? |
Automatic- interlock |
Max.limit swich range Output rotation |
normal |
long |
MR 30
230/400V
50Hz |
123,4 |
60 |
22,7:1 |
2800 |
1,1 |
So |
260 |
430 |
61,6 |
112 |
45,4:1 |
2800 |
1,1 |
So |
130 |
215 |
39 |
165 |
71,8:1 |
2800 |
1,1 |
So |
85 |
135 |
30,8 |
125 |
45,4:1 |
1400 |
0,6 |
So |
130 |
215 |
28,4 |
187 |
98,3:1 |
2800 |
1,1 |
So |
60 |
100 |
21,8 |
220 |
128,5:1 |
2800 |
1,1 |
Ss |
47 |
77 |
19,5 |
180 |
71,8:1 |
1400 |
0,6 |
So |
85 |
135 |
15,4 |
240 |
181,4:1 |
2800 |
1,1 |
Ss |
32 |
55 |
14,2 |
206 |
98,3:1 |
1400 |
0,6 |
So |
60 |
100 |
11,8 |
270 |
238,1:1 |
2800 |
1,1 |
Sd |
25 |
42 |
10,6 |
250 |
264,6:1 |
2800 |
1,1 |
Sd |
23 |
38 |
7,7 |
267 |
181,4:1 |
1400 |
0,6 |
Ss |
32 |
55 |
5,9 |
300 |
238,1:1 |
1400 |
0,6 |
Sd |
25 |
42 |
5,3 |
278 |
264,6:1 |
1400 |
0,6 |
Sd |
23 |
38 |
3,8 |
148 |
181,4:1 |
700 |
0,15 |
Ss |
32 |
55 |
2,9 |
170 |
238,1:1 |
700 |
0,15 |
Sd |
25 |
42 |
2,6 |
160 |
264,6:1 |
700 |
0,15 |
Sd |
23 |
38 |
|
| NOTE: at 60Hz, speed will be 20% higher, torque will be from 0 to 20% less |
| Standard |
| 3-phase motor |
| Terminal box |
| Hollow shaft |
| Any transmission ratio |
| Thermal protection |
| IP 54 |
| 1. Stage plastic gear |
|
|
| Options |
| D.C./A.C. motor |
| Emergency hand crank |
| Stub shaft |
| Spring actuated single disk brake |
| Mounting angle |
| different versions of built-in limit switches |
| 1. Stage steel gear |
|
|
|
| |
|
